Kablo Yapısı
CONDUCTOR : Up to 25mm2 class 6 copper wires, 25mm2 and above sections class 5 wires. (tinned conductor on request)
SEPARATOR : A suitable tape may be applied over the conductor
INSULATION : 3GI3 type rubber compound
CORE IDENTIFICATION : Acc. to VDE0293-308
SHEATH : 5GM3 type elastomer compound
COLOR : Black (other colors on request)
Çalışma Karakteristlikleri
CONSTRUCTION : DIN VDE 0250-809
GENERAL REQUIREMENTS : DIN VDE 0250-1
GUIDE TO USE : DIN VDE 0298-3
ELECTRİCAL TESTS : DIN VDE 0472-501, 503, 508
NON-ELECTRICAL TESTS : DIN VDE 0472-401, 402, 602, 303, 615
UNDER FIRE CONDITIONS TESTS : DIN VDE 0472-803, 804
FLAME RETARDANT : VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1
OIL RESISTANT : HD/EN/IEC 60811-2-1, DIN VDE 0473-811-2-1
Teknik Özellikleri
RATED VOLTAGE : 300 / 500 V, (0,6 / 1 kV)
MAX. OPERATING AC VOLTAGE : 0,7 / 1.2 kV
MAX. OPERATING DC VOLTAGE : 0,9 / 1.8 kV
AC TEST VOLTAGE : 3,5 kV
CONDUCTOR OPERATİNG TEMPERATURE : Max. 90ºC
CONDUCTOR SHORT-CİRCUİT TEMPERATURE : Max. 250ºC
WORKING TEMPERATURE
FIXED : -50ºC … +90ºC
MOBILE : -35ºC … +90ºC
MIN BENDING RADIUS : VDE 0298-3 Tab. 3
CURRENT CARRYİNG CAPACITIES : VDE 0298-4
TRAVEL SPEED
IN FESTOON SYSTEMS : 180 m / min
GANTRY (REELING OPERATION) : No application
MAX. TENSILE LOAD OF CABLE : 15 N / mm2 for static 30 N / mm2 for dynamic
