Kablo Yapısı
CONDUCTOR : Stranded annealed tinned or bare copper wires According to IEC 60228 – Class 2
INSULATION : PVC insulation (85 °C) Colourless
OUTER JACKET : Polyamide (Nylon) Compound
COLOR : Black
Çalışma Karakteristlikleri
OPERATING TEMPERATURE : -40ºC / +85ºC
RATED VOLTAGE : 600 V
TEST VOLTAGE : 2 kV
BENDING RADIUS : 5 x Outer Diameter
STANDARDS : According to manufacturer’s standard FAA Specification for L 824 – AC No. 150 / 5345-7F
UV RESISTANCE : UL 1581 or ISO 4892-2
OIL RESISTANCE
ABRASION RESISTANT
Teknik Özellikleri
| Construction (*) | Cross Section |
Nominal Overall Diameter (mm) |
Approximate Weight (kg / km) |
Max Resistance of Conductors at 20ºC (ohm / km) |
Current Carrying Capacity at 30ºC (A) |
|---|---|---|---|---|---|
| BCL2 / PVC / PA | 1×4 mm² | 4,2 | 49 | 4,61 | 38 |
